| MT |
|---|
 |
| Type and origin |
|---|
| Power type | Diesel |
|---|
| Builder | Frichs |
|---|
| Build date | 1958–1960 |
|---|
| Total produced | 17 |
|---|
|
| Specifications |
|---|
Configuration:
| |
|---|
| • UIC | Bo′Bo′ |
|---|
| Gauge | 1,435 mm (4 ft 8+1⁄2 in) |
|---|
| Length | 12.49 m (40 ft 11+3⁄4 in) |
|---|
| Loco weight | 52.1 t (51.3 long tons; 57.4 short tons) |
|---|
| Prime mover | Frichs 8.200CV (original)
Maybach-Mercedes MB 820B (rebuilt) |
|---|
| Cylinders | 8 (original)
12 (rebuilt) |
|---|
|
| Performance figures |
|---|
| Maximum speed | 70 km/h (43 mph) (original)
90 km/h (56 mph) (rebuilt) |
|---|
| Power output | 425 hp (317 kW) (original)
491 hp (366 kW) (rebuilt) |
|---|
|
| Career |
|---|
| Operators | DSB |
|---|
| Retired | 1990–2000 |
|---|
|
The class MT was a class of diesel-electric locomotives of the Danish State Railways (DSB). Built by Danish manufacturer Frichs, the locomotives entered service in 1958–1960. They were primarily used for heavy shunting and branch line trains. A total of 17 units were built, numbered 151–167.
The original Frichs V8 diesel engines proved unreliable, and the locomotives were rebuilt with Maybach-Mercedes V12 engines during 1969–1971.
The first class MT unit was retired in 1990 after a shunting accident, though the remaining locomotives were not retired from DSB service until 1997–2000. MT 166 remained in use as a service locomotive (tjenestelokomotiv) until 2006.
