Endeavour 33

Endeavour 33

Development
Designer	Bruce Kelley
Location	United States
Year	1983
Builder	Endeavour Yacht Corp.
Name	Endeavour 33
Boat
Displacement	11,350 lb (5,148 kg)
Draft	4.50 ft (1.37 m)
Hull
Type	Monohull
Construction	Fiberglass
LOA	33.00 ft (10.06 m)
LWL	27.50 ft (8.38 m)
Beam	11.50 ft (3.51 m)
Engine type	Yanmar 22 hp (16 kW) diesel engine
Hull appendages
Keel/board type	fin keel
Ballast	4,600 lb (2,087 kg)
Rudder	skeg-mounted spade-type rudder
Rig
Rig type	Bermuda rig
I foretriangle height	45.00 ft (13.72 m)
J foretriangle base	13.82 ft (4.21 m)
P mainsail luff	39.00 ft (11.89 m)
E mainsail foot	11.72 ft (3.57 m)
Sails
Sailplan	Masthead sloop
Mainsail area	228.54 sq ft (21.232 m2)
Jib/genoa area	310.95 sq ft (28.888 m2)
Total sail area	539.49 sq ft (50.120 m2)
Racing
PHRF	168 (average)

The Endeavour 33 is an American sailboat, that was designed by Bruce Kelley and first built in 1983.¹²³

The design was built by Endeavour Yacht Corporation in the United States between 1983 and 1986, but it is now out of production.¹³⁴

The Endeavour 33 is a small recreational keelboat, built predominantly of fiberglass, with wood trim. It has a masthead sloop rig, a raked stem, a near-vertical transom, a skeg-mounted rudder controlled by a wheel and a fixed fin keel. It displaces 11,350 lb (5,148 kg) and carries 4,600 lb (2,087 kg) of ballast.¹³

The boat has a draft of 4.50 ft (1.37 m) with the standard keel fitted.¹³

The boat is fitted with a Japanese Yanmar diesel engine of 22 hp (16 kW). The fuel tank holds 36 U.S. gallons (140 L; 30 imp gal) and the fresh water tank also has a capacity of 36 U.S. gallons (140 L; 30 imp gal).¹³

The design has a PHRF racing average handicap of 168 with a high of 180 and low of 162. It has a hull speed of 7.03 kn (13.02 km/h).³⁵
